Technical Data

Open all Close all

Standard engine data

Engine manufacturer	Yanmar
Motor type	3TNV80FT
Cylinder	3
Drive output	18.4 kW 18.4 kW
Drive output	25 PS 24.7 HP
At max. rpm	2,600 U/min 2,600 rpm
Cylinder capacity	1,226 cm³ 74.82 in³
Type of coolant	Water
Exhaust standard level	V
Exhaust aftertreatment	-
Average sound power level LwA (operator's canopy)	99.3 dB(A)
Guaranteed sound power level LwA (operator's canopy)	101 dB(A)
Specified sound pressure level LpA (operator's canopy)	84 dB(A)
Average sound power level LwA (cabin)	99.3 dB(A)
Guaranteed sound power level LwA (cabin)	101 dB(A)
Specified sound pressure level LpA (cabin)	80 dB(A)

Engine data Option 1

Engine manufacturer	Yanmar
Motor type	3TNV86CHT
Cylinder	3
Drive output	33.3 kW 33.3 kW
Drive output	45.3 PS 44.7 HP
At max. rpm	2,600 U/min 2,600 rpm
Cylinder capacity	1,568 cm³ 95.69 in³
Type of coolant	Water
Exhaust standard level	V
Exhaust aftertreatment	DOC/DPF
Average sound power level LwA (operator's canopy)	98.1 dB(A)
Guaranteed sound power level LwA (operator's canopy)	100 dB(A)
Specified sound pressure level LpA (operator's canopy)	84 dB(A)
Average sound power level LwA (cabin)	98.1 dB(A)
Guaranteed sound power level LwA (cabin)	100 dB(A)
Specified sound pressure level LpA (cabin)	80 dB(A)

Engine data Option 2

Engine manufacturer	Yanmar
Motor type	3TNV86CHT
Cylinder	3
Drive output	40.1 kW 40.1 kW
Drive output	54.5 PS 53.8 HP
At max. rpm	2,600 U/min 2,600 rpm
Cylinder capacity	1,568 cm³ 95.69 in³
Type of coolant	Water
Exhaust standard level	V
Exhaust aftertreatment	DOC/DPF
Average sound power level LwA (cabin)	97.7 dB(A)
Guaranteed sound power level LwA (cabin)	100 dB(A)
Specified sound pressure level LpA (cabin)	76 dB(A)

Electrical system

Operating voltage	12 V
Battery	77 Ah
Alternator	80 A

Weights

Bucket capacity (standard bucket)	0.42 m³
Operating weight	2,800 - 3,300 kg 6,173 - 7,275 lb
Tipping load with bucket – machine straight, loading frame horizontal	1,910 - 2,640 kg 4,211 - 5,820 lb
Tipping load with bucket – machine pivoted, loading frame horizontal	1,600 - 2,200 kg 3,527 - 4,850 lb
Tipping load with pallet fork – machine straight, loading frame horizontal	1,550 - 2,140 kg 3,417 - 4,718 lb
Tipping load with pallet fork – machine pivoted, loading frame horizontal	1,310 - 1,800 kg 2,888 - 3,968 lb

Driver's cab

Driver's cab

FSD (EPS, cabin)

Filling levels

Tank capacity for fuel	50 l 13.21 US gal
Tank capacity for hydraulic oil	30 l 7.93 US gal

Drive system

Type of drive	electronically controlled
Drive unit	Hydrostatic via transfer gearbox and universal joint shaft
Speed levels	2
Axle	PA940
Travel speed Standard	0 - 20 km/h 0 - 12.43 mph
Travel speed Option 1	0 - 30 km/h 0 - 18.64 mph
Operating brake	Multi-disc brake on front axle acting on rear axle via universal joint shaft
Parking brake	Electro-hydraulic multi-disc brakes with spring suspension in the front axle acting on rear axle via articulated universal joint shaft
Differential lock	100 % front axle + rear axle

Hydraulic system

Drive hydraulics working pressure (max.)	400 (470) bar 5,802 (6,817) psi
Work hydraulics discharge volume (max.)	41,6 (49,5 - 84) l/min 10´.99 (13.08 - 22.19) gpm
Work hydraulics working pressure (max.)	210 bar 3,046 psi

Kinematics

Kinematics type	P
Lifting cylinder	2
Tipping cylinder	1
Quick change system	hydraulic

Steering

Steering type	hydraulically activated articulated pendulum steering
Steering cylinder	1
Oscillating angle	± 8 degree

Other information

FSD = overhead guard EPS = Easy Protection System (fold-down overhead guard) DPF = diesel particulate filter DOC = diesel oxidation catalyst Tipping load calculation pursuant to ISO 14397
